Provide Stable And High-Quality Steam

Miura developed a new feed water control method called the twin water level control method. This method is for keeping the best

ebullition condition and the equalizing head effect in the water tubes by changing the water level automatically as the combustion load

Space Saving

Being once-through boilers, the Miura EI Series are more compact than former series. For example, Miura EI-1000 is 22% smaller than the former boiler which has the same equivalent output, and i ts required floor area is only 2.5 m² . This compactness enables the user to make full use of limited space and renders the boiler room spacious.

ω (omega) Flows Structure That Enhances Boiler Effciency

The Miura EI 1500 - 2000 Series are composed of upper and lower headers and a group of vertically mounted water tubes which is wedged at both ends. This computer designed boiler result in a more spacious heat transfer area and heat absorption through the contract-heat transfer area is greatly enhanced. The combustion gas, flows into the chamber then spread out the left and right side of the chamber where water tubes are arranged uniformly.

Steam Available Use Only 4 Or 5 Minutes After Ignition

It takes only 4 or 5 minutes after ignition to start producing steam at a predetermined pressure, which allows quickly get to work on operations.

Quite Operation

The operating noise will not distrub the operator or any person working nearby in the morning or late at night.
